The XS412 Concrete Mixer Truck is a high-performance 12m³ Ready Mix Concrete Truck engineered for commercial concrete transportation, infrastructure construction, industrial projects, and large-scale building applications. Combining a heavy-duty Sinotruk 8×4 chassis, powerful 380 HP Weichai engine, and an efficient closed-loop hydraulic system, this Transit Mixer Truck delivers reliable concrete mixing, fast discharge, and low operating costs throughout every delivery cycle.
Designed for continuous operation under demanding job site conditions, the XS412 ensures consistent concrete quality while maximizing transport efficiency and fleet productivity.
Modern construction projects require dependable concrete transportation equipment capable of maintaining concrete quality from batching plant to placement.
The XS412 combines a large-capacity mixing drum, intelligent hydraulic drive system, and durable heavy-duty chassis to deliver reliable performance for ready-mix suppliers and construction contractors.
Key advantages include:
12 m³ effective mixing capacity
High-speed loading and discharge
Low concrete residual rate
Heavy-duty Sinotruk 8×4 chassis
Powerful 380 HP diesel engine
Efficient closed-loop hydraulic system
Reliable air-pressure water supply
Low maintenance and long service life
Whether operating as a Concrete Delivery Truck, Transit Mixer Truck, or Ready Mix Concrete Truck, the XS412 is built to maximize productivity and reduce transportation costs.
| Parameter | Specification |
|---|---|
| Model | XS412 |
| Curb Weight | 15,500 kg |
| Maximum Gross Vehicle Weight | 31,000 kg |
| Overall Dimensions (L × W × H) | 10,320 × 2,525 × 4,000 mm |
The optimized vehicle layout provides excellent load distribution, driving stability, and maneuverability for urban and long-distance concrete transport.
| Parameter | Specification |
|---|---|
| Water Tank Capacity | 450 L |
| Water Supply Type | Air Pressure System |
The integrated high-pressure water system simplifies drum cleaning while helping maintain concrete quality between deliveries.
The XS412 features a 19.5 m³ geometric drum volume with a 12 m³ effective agitation capacity, making it ideal for high-volume concrete transportation.
Benefits include:
Higher delivery capacity
Fewer transport cycles
Improved fleet efficiency
Reduced operating costs
Consistent concrete mixing during transport
The 12° drum inclination angle promotes smooth material flow during both loading and unloading while maintaining concrete homogeneity.
The high-efficiency drum design supports:
Loading speed ≥ 8 m³/min
Discharge speed ≥ 5 m³/min
Residual rate < 0.4%
These features reduce loading and unloading times while minimizing concrete waste and cleaning requirements.
The drum system accommodates concrete slump ranges from 50 mm to 210 mm, making the XS412 suitable for a wide variety of ready-mix applications.
Supported concrete types include:
Standard ready-mix concrete
Pumped concrete
High-strength concrete
Low-slump paving concrete
Commercial building concrete
Built on a proven Sinotruk 8×4 chassis, the XS412 provides excellent stability and load-carrying capability for demanding construction environments.
Advantages include:
High structural strength
Excellent vehicle balance
Reliable heavy-load performance
Improved driving stability
Long service life
The high-performance Weichai WP10.380E22 diesel engine delivers:
380 HP maximum power
Strong low-speed torque
Reliable hill-climbing capability
Stable performance under full load
Excellent fuel efficiency
Its 9.726 L displacement provides the power required for heavy-duty concrete transportation over diverse road conditions.
The advanced closed-loop hydraulic system integrates high-quality pumps, motors, and reducers to ensure smooth drum operation.
Key benefits include:
Stepless drum speed control
High transmission efficiency
Reduced energy loss
Smooth reversing operation
Lower mechanical wear
Extended component life
This hydraulic design improves mixing consistency while reducing maintenance costs.
The 450 L pressurized water tank supplies high-pressure water for cleaning the drum, charging hopper, and discharge chute after every delivery.
Benefits include:
Faster cleaning
Reduced concrete buildup
Improved drum longevity
Lower maintenance requirements
Consistent concrete quality
The XS412 is an ideal Ready Mix Concrete Truck for transporting concrete from batching plants to commercial construction projects while maintaining uniform mix quality.
Widely used for major infrastructure developments, including:
Highways
Bridges
Tunnels
Airport runways
Rail transit systems
Water conservancy projects
Suitable for transporting concrete to:
Manufacturing plants
Warehouses
Industrial parks
Logistics centers
Heavy equipment foundations
The XS412 efficiently supports:
High-rise buildings
Residential developments
Commercial complexes
Parking structures
Municipal engineering projects
The durable chassis and powerful drivetrain enable reliable concrete delivery across uneven terrain and long transportation distances.
| Advantage | Customer Benefit |
|---|---|
| High Capacity | 12 m³ drum reduces transportation frequency and logistics costs |
| Fast Loading & Discharge | Shorter cycle times improve fleet productivity |
| Low Residual Rate | Less than 0.4% concrete waste lowers material costs |
| Reliable Chassis | Heavy-duty Sinotruk platform ensures long-term durability |
| Powerful Engine | 380 HP delivers dependable performance under full load |
| Efficient Hydraulic System | Smooth drum rotation with reduced maintenance requirements |
| Global Support | Comprehensive worldwide technical service and spare parts supply |
Our international service network provides complete lifecycle support to maximize fleet availability and operational efficiency.
Support services include:
15-Minute Response – Immediate technical assistance
2-Hour Support – Rapid remote or on-site service
24-Hour Resolution Target – Fast troubleshooting and repair
Equipment commissioning
Operator training
Preventive maintenance
Spare parts supply
Fleet technical consulting
Remote diagnostics
The XS412 features a 12 m³ effective agitation capacity and a 19.5 m³ geometric drum volume, making it ideal for commercial ready-mix transportation and large infrastructure projects.
The truck is suitable for ready-mix concrete, pumped concrete, low-slump paving concrete, high-strength concrete, and other commercial concrete mixes with slump values ranging from 50 mm to 210 mm.
The closed-loop hydraulic system provides stepless drum speed adjustment, smooth reversing, reduced energy loss, and lower wear, ensuring consistent concrete mixing during transportation.
A discharge residual rate of less than 0.4% minimizes concrete waste, reduces cleaning time, improves delivery efficiency, and lowers overall operating costs.
Yes. We provide equipment commissioning, operator training, spare parts supply, preventive maintenance, remote diagnostics, technical consulting, and comprehensive global after-sales support for customers worldwide.
